Disaster Prevention and Response

Harness the power of drones to capture critical visual and thermal data, enhancing prevention strategies and response tactics during natural disasters, including floods, landslides, earthquakes, and more.

Portable and Rapid Response

The Mavic 3T offers unparalleled portability for disaster assesment and quick reconstruction missions. Easy to carry on patrol vehicles and equipped with visual and thermal cameras, it's the ideal solution for initial risk evaluations.

Drone Platform

LE Drones - Disaster Prevention and Response

DJI Mavic 3T

Weight: 920 g
Max Flight Time (no wind): 45 mins
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Environment Adaptability: Max Take-off Altitude Above Sea Level 6000m; Max Wind Speed Resistance 12 m/s
Wide Camera: 1/2-inch CMOS, Effective pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective pixels: 12 MP
Thermal Camera: Video Resolution 640×512@30Hz
Compatible with RTK module and DJI Cellular module

Payload And Software

LE Drones - Disaster Prevention and Response

DJI Pilot 2

Ground control

Workflow

  1. Mission Execution:
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views to evaluate the situation.
    – Use orbit flights to perform 360 circular flights around the structure, facilitating the risk evaluation.
    – Select a suitable infrared palette and gain mode for the conditions at hand.
  2. Post Mission Documentation:
    – Map the affected areas for post-incident reports and reforestation efforts.

Versatile Aerial Thermal Reconnaissance

The Matrice 30T strikes the perfect balance between portability and performance. It integrates a hybrid sensor with visual, thermal, and laser range finder capabilities for optimal performance in a variety of disaster conditions.

Drone Platform

LE Drones - Disaster Prevention and Response

Matrice 30T

Weight (incl. two batteries): 3770 ± 10 g.
Max Flight Time: 41 min.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: Max Service Ceiling Above Sea Level (without other payload) 7,000 m (with 1676 propellers); Max Wind Resistance 12 m/s.
Zoom camera: 1/2-inch CMOS, Effective pixels: 48MP.

Payload And Software

LE Drones - Disaster Prevention and Response

DJI Pilot 2

Ground control

LE Drones - Disaster Prevention and Response

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views to evaluate the situation.
    – Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
    – Get the coordinates of hotspots using the laser range finder and the Pin Point function or draw out routes and areas to avoid.
    – Share Pin Point coordinates to ground teams through DJI Pilots 2 QR code or DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from the drone SD card to be used as supporting documentation for post-disaster analysis.

Portable Pre and Post Disaster Mapping

The DJI Mavic 3E is a portable surveying and mapping drone suitable for single-pilot operations. Paired with DJI Terra, it can generate accurate 2D and 3D models that can be used for prevention or post-disaster efforts.

Drone Platform

LE Drones - Disaster Prevention and Response

DJI Mavic 3E

Weight: 915 g.
Max Flight Time (no wind): 45 mins.
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.
Environment Adaptability: Max Take-off Altitude Above Sea Level 6,000 m; Max Wind Speed Resistance 12 m/s.
Wide Camera: 4/3 CMOS, Effective pixels: 20 MP.
Mechanical Shutter: 8-1/2000 s, supports rapid 0.7-second interval shooting.
Compatible with RTK module and DJI Cellular module.

Payload And Software

LE Drones - Disaster Prevention and Response

DJI Pilot 2

Ground control

LE Drones - Disaster Prevention and Response

DJI Terra

Modeling and flight mission plan

Workflow

  1. Data Collection:
    – Plan a 2D or Smart Oblique Mission based on the actual landscape situation to generate regular orthomosaic images or 3D Models.
  2. Data Processing:
    – Import to DJI Terra to process orthomosaic maps or 3D models.
  3. Data Analysis:
    – Perform analysis on the situation directly in DJI Terra or import the outputs to the preferred third-party software for further analysis.

Questions? We're always happy to help!​

Call (800) 918-9128 or complete form below
