Private Security

Swiftly patrol large areas to identify potential security threats and support ground teams with enhanced situational awareness.

Automated Patrol

The DJI Dock 2 enables private security teams to continuously perform scheduled and on-demand aerial patrols. Equipped with visual and thermal sensors, the Matrice 3TD offers superior performance in detecting potential risks not captured by fixed security systems. Integrate external alarm systems through the DJI FlightHub 2 API for an automated aerial security solution.

Drone Platform

LE Drones - Private Security

DJI Dock 2

Weight: 34 kg (without the drone).
Size: length 570 mm, width 583 mm, height 465 mm.
Environment adaptability: -25℃-45℃ working temperature, IP55 Rate, max operation height 4,000 m.
Max Operating Radius: 10 km.

LE Drones - Private Security

Matrice 3TD

Weigh: 1410 g.
Size: length 335 mm, width 398 mm, height 153 mm(without propellers).
Max flight time: 50 minutes.
Max Operating Radius: 10 km.
Wide camera: 1/1.32'' CMOS, 48MP.
Tele camera: 1/2" CMOS, 12MP.
Thermal camera: UHR Infrared Image Mode 1280 × 1024@30fps.
Environment adaptability: -25℃-45℃ working temperature, IP55 Rate, max operation height 4,000 m.

Payload And Software

LE Drones - Private Security

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Planning:
    (1) For Patrol Missions:
    – Using the waypoint mission planning feature in DJI FlightHub 2, determine the perimeter to be inspected, making sure to cover potential blind spots or frequently breached points.
    (2) For Alarm Response:
    – Using the DJI FlightHub 2 platform, take control of the DJI Dock 2 closest to the alarm location and launch the drone.  Search for the coordinates on the map and set it as Fly-to destination.
  2. Mission Execution:
    – The drone automatically takes off and starts the flight mission.
    – The pilot can take over live flight control and operate the drone, payload, and switch between the Wide, Tele, and IR cameras as needed.
    – Live stream the drone images to command centers through DJI FlightHub 2.
  3. Post Mission Documentation:
    – Captured videos and photos will automatically be uploaded to DJI FlightHub 2 to be used as evidence or debrief documentation.

Versatile Thermal

The Matrice 30T strikes the perfect balance between portability and performance. It integrates a hybrid sensor with visual, thermal, and laser range finder capabilities into a mid-size, weather and dust-proof airframe for optimal operation in challenging environments.

Drone Platform

LE Drones - Private Security

Matrice 30T

Weight (incl. two batteries): 3770 ± 10 g.
Max Flight Time: 41 min.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: Max Service Ceiling Above Sea Level (without other payload) 7,000 m (with 1676 propellers); Max Wind Resistance 12 m/s.
Zoom camera: 1/2-inch CMOS, Effective pixels: 48MP.

Payload And Software

LE Drones - Private Security

DJI Pilot 2

Ground control

LE Drones - Private Security

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Using DJI Pilot 2 App, add the alarm location to the map as a GPS Pin.
    – In DJI Pilot 2 camera view, use AR of the pin to guide the pilot toward the correct coordinates.
    – Fly manually over the incident area switching between visual and thermal views for enhanced situational awareness.
    – Use the Smart Track feature to take cognitive load off the pilots and keep target moving objects centered.
    – Live stream the drone images to command centers through DJI FlightHub 2.
  2. Post Mission Documentation:
    – Captured videos and photos can be uploaded to DJI FlightHub 2 or downloaded from the SD card to be used as evidence or debrief documentation.

Portable Patrol and Response

The Mavic 3T offers unparalleled portability and performance for private security teams. Easy to carry and equipped with visual and thermal cameras, it provides a quick assessment in the event of a security breach. Livestream the aerial feed to command centers through DJI FlightHub 2 for enhanced cross-team collaboration.

Drone Platform

LE Drones - Private Security

DJI Mavic 3T

Weight: 920 g
Max Flight Time (no wind): 45 mins
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Environment Adaptability: Max Take-off Altitude Above Sea Level 6000m; Max Wind Speed Resistance 12 m/s
Wide Camera: 1/2-inch CMOS, Effective pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective pixels: 12 MP
Thermal Camera: Video Resolution 640×512@30Hz
Compatible with RTK module and DJI Cellular module

Payload And Software

LE Drones - Private Security

DJI Pilot 2

Ground control

LE Drones - Private Security

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    (1) For Alarm Response:
    – Using DJI Pilot 2 App, add the last known location to the map as a GPS Pin.
    – Fly manually over to the incident area switching between visual and thermal views for enhanced situational awareness.
    (2) For Patrol Missions:
    – Plan perimeter mission using DJI Pilot 2 or DJI FlightHub 2 waypoint mission planning feature.
    – Select the flight plan and execute the mission.
    – Stop and resume the mission depending on the needs.
    – Live stream the drone images to command centers through DJI FlightHub 2.
  2. Post Mission Documentation:
    – Captured videos and photos can be uploaded to DJI FlightHub 2 or downloaded from the SD card to be used as evidence or debrief documentation.
