Additional Response

Diversify your response scope for Hazmat, water rescue, and other unexpected emergencies with multipurpose aerial support.

Hazmat Response

The Matrice 350 RTK, equipped with the Zenmuse H30T, brings enhanced thermal capabilities to Hazmat response. Expand the M350 RTK's capabilities with a third-party payload for gas detection sensing.

Drone Platform

LE Drones - Additional Response

Matrice 350 RTK

Weight: Approx. 6.47 kg(with single downward gimbal and two TB65 batteries).
Max Flight Time: 55 minutes.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: IP55, Max Service Ceiling Above Sea Level 7,000 m (with 1676 propellers,without other payload); Max Wind Resistance 12 m/s.

Payload And Software

LE Drones - Additional Response

Zenmuse H30T

Weight: 920±5 g.
Ingress Protection Rating: IP54.
Zoom Camera: 1/1.8-inch CMOS, Effective Pixels: 40 MP.
Wide-Angle Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP.
Infrared Thermal Camera: 1280×1024@30fps.
Laser Range Finder: max range 3000 m.

LE Drones - Additional Response

DJI Pilot 2

Ground control

LE Drones - Additional Response

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Fly manually over the affected area to determine the severity of the situation. Switch between infrared and visual views to evaluate the situation.
    – Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
    – Install the IR Density Filter to increase the measurement range of the thermal sensor.
    – Share the coordinates with ground teams through the DJI Pilot 2 QR code or DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from the payload SD card to be used as supporting documentation for post-disaster analysis.

Water Rescue

The Matrice 30T strikes the perfect balance between portability and performance, integrating a hybrid sensor with visual, thermal, and laser range finder capabilities for optimal performance in a variety of rescue scenarios.

Drone Platform

LE Drones - Additional Response

Matrice 30T

Weight (incl. two batteries): 3770 ± 10 g.
Max Flight Time: 41 min.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: Max Service Ceiling Above Sea Level (without other payload) 7,000 m (with 1676 propellers); Max Wind Resistance 12 m/s.
Zoom camera: 1/2-inch CMOS, Effective pixels: 48MP.

Payload And Software

LE Drones - Additional Response

DJI Pilot 2

Ground control

LE Drones - Additional Response

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Using DJI Pilot 2 app, add the last known location to the map as a GPS Pin.
    – In the DJI Pilot 2 camera view, use the AR of the pin to fly directly toward the correct coordinates.
    – Fly manually over search areas switching between visual and thermal views to identify the missing person.
    – Utilize white hot or black hot palettes as needed along with high gain mode.
    – Once the subject is identified. Get accurate coordinates using the Pin Point function. Share Pin Point coordinates to ground teams through DJI Pilots 2 QR code or DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from the drone SD card to be used as supporting documentation for post-disaster analysis.

Brush Clearance and Inspection

The Mavic 3T offers unparalleled portability and performance for scanning large areas with ease. Its small airframe is convenient to carry on patrol vehicles, and with visual and thermal cameras equipped, it's the ideal solution for identifying wildfire risks.

Drone Platform

LE Drones - Additional Response

DJI Mavic 3T

Weight: 920 g
Max Flight Time (no wind): 45 mins
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Environment Adaptability: Max Take-off Altitude Above Sea Level 6000m; Max Wind Speed Resistance 12 m/s
Wide Camera: 1/2-inch CMOS, Effective pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective pixels: 12 MP
Thermal Camera: Video Resolution 640×512@30Hz
Compatible with RTK module and DJI Cellular module

Payload And Software

LE Drones - Additional Response

DJI Pilot 2

Ground control

LE Drones - Additional Response

DJI Terra

Modeling and flight mission plan

LE Drones - Additional Response

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Plan a 2D or Smart Oblique Mission based on the actual landscape situation to generate regular orthomosaic images or 3D Models.
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views (wide or zoom) to evaluate the infrastructure and vegetation.
  2. Post Mission Documentation:
    – Map the affected areas for post-incident reports and preventative action briefs.
