Search and Rescue

Swiftly aid search and rescue missions by covering extensive and difficult-to-navigate landscapes, utilizing aerial thermal imaging to pinpoint the whereabouts of lost individuals.

Portable Thermal

The Mavic 3T offers unparalleled portability and thermal capabilities for rescue teams. Easy to carry and equipped with visual and thermal cameras, it provides quick aerial support when time matters the most. Livestream the aerial feed to command centers through DJI FlightHub 2 for enhanced cross-team collaboration.

Drone Platform

LE Drones - Search and Rescue

DJI Mavic 3T

Weight: 920 g
Max Flight Time (no wind): 45 mins
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Environment Adaptability: Max Take-off Altitude Above Sea Level 6000m; Max Wind Speed Resistance 12 m/s
Wide Camera: 1/2-inch CMOS, Effective pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective pixels: 12 MP
Thermal Camera: Video Resolution 640×512@30Hz
Compatible with RTK module and DJI Cellular module

Payload And Software

LE Drones - Search and Rescue

DJI Pilot 2

Ground control

LE Drones - Search and Rescue

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

Mission Execution:

  1. – Fly manually over the last known location following a search pattern such as the wheel route.
  2. – Draw points, lines, or polygons on a map on DJI FlightHub 2 to mirror the last known location, trails, or key areas of interest.
  3. – Select a suitable infrared palette and gain mode for the conditions at hand. White Hot and Black Hot palettes are preferred.
  4. – Switch between infrared and visual cameras. Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
  5. – As the situation allows, generate a rapid 2D map on DJI FlightHub 2 to provide a better understanding of search area and routes.
  6. – Once the subject is identified, mark the location with the drone flying over.
  7. – Communicate with the rescuee and rescue teams using the speaker if applicable.
  8. – Support team on the rescue mission providing lighting from the drone using the spotlight.

Versatile Thermal

The Matrice 30T strikes the perfect balance between portability and performance. It integrates a hybrid sensor with visual, thermal, and laser range finder capabilities into a mid-size, weather and dust-proof airframe for optimal operation in challenging environments.

Drone Platform

LE Drones - Search and Rescue

Matrice 30T

Weight (incl. two batteries): 3770 ± 10 g.
Max Flight Time: 41 min.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: Max Service Ceiling Above Sea Level (without other payload) 7,000 m (with 1676 propellers); Max Wind Resistance 12 m/s.
Zoom camera: 1/2-inch CMOS, Effective pixels: 48MP.

Payload And Software

LE Drones - Search and Rescue

DJI Pilot 2

Ground control

LE Drones - Search and Rescue

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

Mission Execution:

  1. – Fly manually over the last known location following a search pattern such as the wheel route.
  2. – Draw points, lines, or polygons on a map on DJI FlightHub 2 to mirror the last known location, trails, or key areas of interest.
  3. – Select a suitable infrared palette and gain mode for the conditions at hand. White Hot and Black Hot palettes are preferred.
  4. – Switch between infrared and visual cameras. Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
  5. – For night missions, operators can choose to disable the IR Cut Filter of the zoom camera for enhanced night visibility.
  6. – As the situation allows, generate a rapid 2D map on DJI FlightHub 2 to provide a better understanding of search area and routes.
  7. – Once the subject is identified. Get the coordinates of subject using the laser range finder and the Pin Point function or draw out routes and areas to avoid.
  8. – Share Pin Point coordinates to ground teams through DJI Pilots 2 QR code or DJI FlightHub 2.
  9. – Communicate with the rescuee and rescue teams using the speaker if applicable.
  10. – Support team on the rescue mission providing lighting from the drone using the spotlight.

Robust Multi-Purposed Search

The Matrice 350 RTK, equipped with the Zenmuse H30T, brings enhanced thermal capabilities to search and rescue teams. Add a spotlight and speakers to aid the ground team during rescue missions.

Drone Platform

LE Drones - Search and Rescue

Matrice 350 RTK

Weight: Approx. 6.47 kg(with single downward gimbal and two TB65 batteries).
Max Flight Time: 55 minutes.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: IP55, Max Service Ceiling Above Sea Level 7,000 m (with 1676 propellers,without other payload); Max Wind Resistance 12 m/s.

Payload And Software

LE Drones - Search and Rescue

Zenmuse H30T

Weight: 920±5 g.
Ingress Protection Rating: IP54.
Zoom Camera: 1/1.8-inch CMOS, Effective Pixels: 40 MP.
Wide-Angle Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP.
Infrared Thermal Camera: 1280×1024@30fps.
Laser Range Finder: max range 3000 m.

LE Drones - Search and Rescue

DJI Pilot 2

Ground control

LE Drones - Search and Rescue

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

Mission Execution:

  1. – Fly manually over the last known location following a search pattern such as the wheel route.
  2. – Draw points, lines, or polygons on a map on DJI FlightHub 2 to mirror the last known location, trails, or key areas of interest.
  3. – Select a suitable infrared palette and gain mode for the conditions at hand. White Hot and Black Hot palettes are preferred.
  4. – Switch between infrared and visual cameras. Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
  5. – For night missions, operators can choose to disable the IR Cut filter and enabling the IR spotlight of the zoom camera for enhanced night visibility.
  6. – As the situation allows, generate a rapid 2D map on DJI FlightHub 2 to provide a better understanding of search area and routes.
  7. – Once the subject is identified. Get the coordinates of subject using the laser range finder and the Pin Point function or draw out routes and areas to avoid.
  8. – Share Pin Point coordinates to ground teams through DJI Pilots 2 QR code or DJI FlightHub 2.
  9. – Communicate with the rescuee and rescue teams using the speaker if applicable.
  10. – Support team on the rescue mission providing lighting from the drone using the spotlight.
