Urban Fires

Tackle urban fire emergencies with drone thermal readings; improve your response efforts by localizing hotspots and deploying teams more effectively.

QuickRiskAssessment

The Mavic 3T offers unparalleled portability for quick deployment missions. Easy to carry on fire response vehicles and equipped with visual and thermal cameras, it's the ideal solution for initial risk evaluations.

Drone Platform

LE Drones - Urban Fires

DJI Mavic 3T

Weight: 920 g
Max Flight Time (no wind): 45 mins
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
Environment Adaptability: Max Take-off Altitude Above Sea Level 6000m; Max Wind Speed Resistance 12 m/s
Wide Camera: 1/2-inch CMOS, Effective pixels: 48 MP
Tele Camera: 1/2-inch CMOS, Effective pixels: 12 MP
Thermal Camera: Video Resolution 640×512@30Hz
Compatible with RTK module and DJI Cellular module

Payload And Software

LE Drones - Urban Fires

DJI Pilot 2

Ground control

LE Drones - Urban Fires

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views to evaluate the situation.
    – Select a suitable infrared palette and gain mode for the conditions at hand.
    – Use orbit flights to perform 360 circular flights around the structure, facilitating the risk evaluation.
    – Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
    – Share live feed with command staff through DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from drone SD card to be used as evidence or debrief documentation.

High Performance Fire Response

The Matrice 350 RTK, equipped with the Zenmuse H30T, brings enhanced thermal capabilities to fire response. Using the new H30T Night Scene mode, fire brigades can now gain valuable insights during low-light operations

Drone Platform

LE Drones - Urban Fires

Matrice 350 RTK

Weight: Approx. 6.47 kg(with single downward gimbal and two TB65 batteries).
Max Flight Time: 55 minutes.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: IP55, Max Service Ceiling Above Sea Level 7,000 m (with 1676 propellers,without other payload); Max Wind Resistance 12 m/s.

Payload And Software

LE Drones - Urban Fires

Zenmuse H30T

Weight: 920±5 g.
Ingress Protection Rating: IP54.
Zoom Camera: 1/1.8-inch CMOS, Effective Pixels: 40 MP.
Wide-Angle Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP.
Infrared Thermal Camera: 1280×1024@30fps.
Laser Range Finder: max range 3000 m.

LE Drones - Urban Fires

DJI Pilot 2

Ground control

LE Drones - Urban Fires

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views to evaluate the situation.
    – Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
    – Select a suitable infrared palette and gain mode for conditions at hand.
    – Install the IR Density Filter to increase the measurement range of the thermal sensor.
    – Get the coordinates of hotspots using the laser range finder and the Pin Point function.
    – Share the coordinates with ground teams through the DJI Pilot 2 QR code or DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 to be used as evidence or debrief documentation.

Versatile Aerial Thermal Reconnaissance

The Matrice 30T strikes the perfect balance between portability and performance. It integrates a hybrid sensor with visual, thermal, and laser range finder capabilities, ensuring optimal performance across a variety of fire emergencies.

Drone Platform

LE Drones - Urban Fires

Matrice 30T

Weight (incl. two batteries): 3770 ± 10 g.
Max Flight Time: 41 min.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: Max Service Ceiling Above Sea Level (without other payload) 7,000 m (with 1676 propellers); Max Wind Resistance 12 m/s.
Zoom camera: 1/2-inch CMOS, Effective pixels: 48MP.

Payload And Software

LE Drones - Urban Fires

DJI Pilot 2

Ground control

LE Drones - Urban Fires

DJI FlightHub 2

Drone and dock's cloud management system

Workflow

  1. Mission Execution:
    – Fly manually over the affected area looking for hotspots. Switch between infrared and visual views to evaluate the situation.
    – Use Orbit flights to perform 360 circular flights around the structure, facilitating the risk evaluation.
    – Select a suitable infrared palette and gain mode for the conditions at hand.
    – Use the Link Zoom feature to zoom in simultaneously with thermal and visual sensors.
    – Mark hotspots to revisit using the laser range finder and the Pin Point function.
    – Share live feed with command staff through DJI FlightHub 2.
  2. Post Mission Documentation:
    – Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from the drone SD card to be used as evidence or debrief documentation.
