Collision Reconstruction and Forensics

Clear roads faster with efficient and accurate drone-based data collection and reconstruction. Ensure personnel safety and digitize your forensics process.

Portable Scene Reconstruction

The Mavic 3E offers unparalleled portability for quick reconstruction missions. Easy to carry in patrol vehicles and equipped with a 20MP camera and RTK module, it's an ideal solution for fast but accurate scene reconstruction. Paired with DJI Terra and DJI Modify, it can create realistic 3D models to serve as evidence or for forensic analysis.

Drone Platform

LE Drones - Collision Reconstruction and Forensics

DJI Mavic 3E

Weight: 915 g.
Max Flight Time (no wind): 45 mins.
Sensing type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.
Environment Adaptability: Max Take-off Altitude Above Sea Level 6,000 m; Max Wind Speed Resistance 12 m/s.
Wide Camera: 4/3 CMOS, Effective pixels: 20 MP.
Mechanical Shutter: 8-1/2000 s, supports rapid 0.7-second interval shooting.
Compatible with RTK module and DJI Cellular module.

Payload And Software

LE Drones - Collision Reconstruction and Forensics

DJI Pilot 2

Ground control

LE Drones - Collision Reconstruction and Forensics

DJI Terra

Modeling and flight mission plan

LE Drones - Collision Reconstruction and Forensics

DJI Modify

Intelligent 3D model editing software

Workflow

  1. Mission Planning:
    – Plan Mapping Mission based on scene reconstruction needed.
  2. Mission Execution:
    – Execute the planned mission. Complement the images with POI flights using timed photo capture.
    – For night reconstructions, make sure to properly light the scene for accurate data collection.
  3. Post Mission Documentation:
    – Import collected data in DJI Terra to process the scene 3D model.
    – Use DJI Modify to clean a version of the 3D model, remove any floating parts, and improve overall texture quality. Sharing with other stakeholders is also possible.

Large Scale Scene Reconstruction

The Matrice 350 RTK, equipped with the Zenmuse P1, allows law enforcement and forensic teams to map vast incident areas with great quality and accuracy. Process the collected data with DJI Terra and DJI Modify for optimal processing efficiency and modeling quality.

Drone Platform

LE Drones - Collision Reconstruction and Forensics

Matrice 350 RTK

Weight: Approx. 6.47 kg(with single downward gimbal and two TB65 batteries).
Max Flight Time: 55 minutes.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: IP55, Max Service Ceiling Above Sea Level 7,000 m (with 1676 propellers,without other payload); Max Wind Resistance 12 m/s.

Payload And Software

LE Drones - Collision Reconstruction and Forensics

Zenmuse H30T

Weight: 920±5 g.
Ingress Protection Rating: IP54.
Zoom Camera: 1/1.8-inch CMOS, Effective Pixels: 40 MP.
Wide-Angle Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP.
Infrared Thermal Camera: 1280×1024@30fps.
Laser Range Finder: max range 3000 m.

LE Drones - Collision Reconstruction and Forensics

DJI Pilot 2

Ground control

LE Drones - Collision Reconstruction and Forensics

DJI Terra

Modeling and flight mission plan

LE Drones - Collision Reconstruction and Forensics

DJI Modify

Intelligent 3D model editing software

Workflow

  1. Mission Planning:
    – Plan Mapping Mission based on scene reconstruction needed.
  2. Mission Execution:
    – Execute the planned mission. Complement the images with manual flights.
    – For night reconstructions, make sure to properly light the scene for accurate data collection.
  3. Post Mission Documentation:
    – Import collected data in DJI Terra to process the scene 3D model.
    – Use DJI Modify to clean a version of the 3D model, remove any floating parts, and improve overall texture quality. Sharing with other stakeholders is also possible.
