First Response
Reduce response times and allocate resources more effectively with timely Drone as First Responder (DFR) operations.
Painpoints
- Unreliable incident information leads to unprepared ground teams and inefficient resource distribution.
- A lack of manpower in law enforcement departments and large travel distances between incidents leads to delayed response times.
- Police officers often have to navigate between different roles, leaving little time for drone operations.
Advantages
- Drones arrive at the incident first, helping to assess the situation so that command centers can allocate resources accordingly.
- Strategically deploy drones to cut down on response times and to evaluate the urgency of the response needed by ground teams.
- Reduce drone integration friction and increase drone availability by integrating drone-in-a-box solutions for Drone as First Responder Programs.
Solution
Automated Drone as First Reponder
The DJI Dock 2 enables Law Enforcement Departments to significantly reduce response times and provide on-demand aerial support for operations. Equipped with visual and thermal sensors and featuring a reduced installation footprint, the DJI Dock 2 is ideal for clustered deployment across cities and urban areas.
- Thermal and visual sensors to gather comprehensive aerial intel for your missions.
- Compact and lightweight design, easy to deploy in urban environments with limited space.
- Fast and easy deployment, get airborne in around 45 seconds.
- Fly-to missions to optimize flight response.
- Manual controls for developing situations that require human intervention.
- Reduced operational risk with the Task Area Management feature.
Drone Platform
DJI Dock 2
Weight: 34 kg (without the drone).
Size: length 570 mm, width 583 mm, height 465 mm.
Environment adaptability: -25℃-45℃ working temperature, IP55 Rate, max operation height 4,000 m.
Max Operating Radius: 10 km.
Matrice 3TD
Weigh: 1410 g.
Size: length 335 mm, width 398 mm, height 153 mm(without propellers).
Max flight time: 50 minutes.
Max Operating Radius: 10 km.
Wide camera: 1/1.32'' CMOS, 48MP.
Tele camera: 1/2" CMOS, 12MP.
Thermal camera: UHR Infrared Image Mode 1280 × 1024@30fps.
Environment adaptability: -25℃-45℃ working temperature, IP55 Rate, max operation height 4,000 m.
Workflow
- Mission Planning:
– After receiving an incident call, using the DJI FlightHub 2 platform, take control of the DJI Dock 2 closest to the incident location and launch the drone.
– Search for the address on the map and set it as Fly-to destination. - Mission Execution:
– The drone automatically takes off and starts flying to the location.
– The pilot can take over live flight control and operate the drone, payload, and switch between the Wide, Tele, and IR cameras as needed.
– Live stream the drone images to command centers through DJI FlightHub 2. - Post Mission Documentation:
– Captured videos and photos will automatically be uploaded to DJI FlightHub 2 to be used as evidence or debrief documentation.
Versatile Aerial Response
The Matrice 350 RTK sets the standard for high-performance, multipurpose drone solutions. Equipped with the Zenmuse H30T multi-sensor payload, which includes zoom, wide, and thermal cameras, it provides optimal performance for Drone as First Responder programs.
- Robust and weatherproof airframe graded IP55, allows you to fly when is most needed.
- Night Scene Mode and NIR Auxiliary Light features for night operations.
- Optimal operational efficiency with extended flight time of up to 55 min.
- Transmission range up to 20km to cover larger response areas¹.
- Hot-swappable batteries for continuous operation.
- Expandable payload capabilities with speakers, spotlights, and other PSDK options.
Drone Platform
Matrice 350 RTK
Weight: Approx. 6.47 kg(with single downward gimbal and two TB65 batteries).
Max Flight Time: 55 minutes.
Sensing system: Six-directional sensing and positioning.
Environment Adaptability: IP55, Max Service Ceiling Above Sea Level 7,000 m (with 1676 propellers,without other payload); Max Wind Resistance 12 m/s.
Payload And Software
Zenmuse H30T
Weight: 920±5 g.
Ingress Protection Rating: IP54.
Zoom Camera: 1/1.8-inch CMOS, Effective Pixels: 40 MP.
Wide-Angle Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP.
Infrared Thermal Camera: 1280×1024@30fps.
Laser Range Finder: max range 3000 m.
DJI Pilot 2
Ground control
DJI FlightHub 2
Drone and dock's cloud management system
Workflow
- Mission Planning:
– After receiving an incident call, using DJI Pilot 2 App on your DJI RC Plus controller, search for the address on the map and drop a pin. - Mission Execution:
– Pilot can control the drone, payload and switch between the Wide, Tele and IR cameras as needed.
– Live stream the drone images to command centers through DJI FlightHub 2. - Post Mission Documentation:
– Collect the videos and photos captured during the mission through DJI FlightHub 2 or download from the payload SD card to be used as evidence or debrief documentation.
